The Audio-Technica ESE-H Hypercardioid Microphone Element for Engineered Sound Mics features a 100-degree pickup pattern designed for use with selected Engineered Sound microphones.
The Audio-Technica ESE-H Hypercardioid Microphone Element for Engineered Sound Mics is a specialized acoustic component designed for precise audio capture. This element functions as a modular head for specific models within the Engineered Sound microphone series.
The ESE-H utilizes a hypercardioid polar pattern to provide directional audio sensitivity. It features a 100-degree pickup pattern, which defines the specific arc of sound capture for the microphone. This configuration focuses the element's response on the sound source located within that 100-degree field.
This interchangeable element is engineered specifically for use with selected Engineered Sound microphones. The modular design allows for the customization of a microphone's polar pattern to meet the requirements of different professional audio environments. The ESE-H ensures compatibility and consistent performance when integrated with supported Engineered Sound microphone bodies.
| Construction Material | Brass, ABS Resin |
| Self-Noise | 29 dB SPL (A-weighted) |
| Operating Humidity Range | 20% to 90% RH (non-condensing) |
| Transducer Type | Fixed-charge back plate, permanently polarized condenser |
| Maximum Input Sound Level | 134 dB SPL, 1 kHz at 1% T.H.D. |
| Signal-to-Noise Ratio | 65 dB, 1 kHz at 1 Pa |
| Polar Pattern | Hypercardioid |
| Storage Temperature Range | -4°F to 140°F (-20°C to 60°C) |
| Connector Type | Proprietary screw-on |
| Recommended Applications | Speech, Vocal, Conference, Lecture, Teleconferencing |
| Frequency Response | 100 Hz - 17,000 Hz |
| Finish | Matte Black |
| Element Diameter | 0.47 inches (12 mm) |
| Output Polarity | Positive pressure produces positive voltage on pin 2 relative to pin 3 (via host microphone) |
| Element Length | 0.71 inches (18 mm) |
| Operating Temperature Range | 32°F to 104°F (0°C to 40°C) |
| Mounting Type | Screw-on to compatible microphone body |
| Dynamic Range | 107 dB, 1 kHz at Max SPL |
| Directionality | End-address |
| Open Circuit Sensitivity | -38 dB (12.5 mV) re 1V at 1 Pa |
| Power Requirements | 11-52V DC Phantom Power (supplied by host microphone) |
| Element Weight | 0.04 oz (1.2 g) |
| Pickup Angle | 100 degrees |
| Compatibility | Audio-Technica Engineered Sound Series Microphones (e.g., ES915, ES933, ES945, ES947) |
| Impedance | 200 ohms |
| Length | 3 In. |
|---|---|
| Width | 2 In. |
| Height | 1 In. |
| Weight | 1 lbs |
