Name: Audio-Technica ATW-902A System 9 Handheld Wireless System
Brand: Audio-Technica
SKU: TMU-ATW-902A
Availability: InStock

The Audio-Technica ATW-902A System 9 Handheld Wireless System is a comprehensive wireless audio solution designed for handheld applications. This system facilitates reliable audio transmission by combining the ATW-R900a receiver with the ATW-T902a handheld dynamic unidirectional microphone/transmitter. The package includes an AT8456a Quiet-Flex stand clamp to ensure the system is ready for immediate mounting and use.

Core System Components

The ATW-902A package consists of dedicated hardware engineered for synchronized wireless operation.

ATW-R900a Receiver

The ATW-R900a receiver acts as the primary signal processing hub for the System 9. It captures the wireless signals sent from the handheld transmitter to provide a stable and consistent audio feed for connected sound systems.

ATW-T902a Handheld Transmitter

The ATW-T902a integrates a microphone and a transmitter into a single handheld unit. This component features a dynamic microphone element that provides reliable performance in diverse environments. The unidirectional polar pattern focuses on the primary sound source directly in front of the microphone, which effectively minimizes background noise and reduces the potential for feedback during operation.

Mounting and Accessories

The inclusion of the AT8456a Quiet-Flex stand clamp enhances the utility of the ATW-902A system. This accessory allows for the secure mounting of the ATW-T902a transmitter onto standard microphone stands, providing flexibility for presenters and performers who require hands-free operation or a stable resting position for the microphone.

Operating Frequencies	VHF highband, 169 MHz to 172 MHz
Modulation Mode	FM
Maximum Deviation	+/-10 kHz
Frequency Response	80 Hz to 13 kHz
Operating Range	200' (60 m) typical; Open range environment with no interfering signals
Total Harmonic Distortion	<1% (at 1 kHz, +/-10 kHz deviation)
Operating Temperature Range	40° F (4° C) to 110° F (43° C); Battery performance may be reduced at very low temperatures
Notes	First-generation System 9 (original) components: ATW-R900 receiver; ATW-T901 body-pack transmitter; ATW-T902 unidirectional dynamic microphone transmitter; Click here for the original System 9 Owner's Manual.
RF Power Output	10 mW
Spurious Emissions	Following federal and national regulations
Battery Type	Two 1.5V AA not included
Battery Life	8 hours (alkaline); Depending on battery type and use pattern
Dimensions	9.91" (251.8 mm) long, 2.11" (53.5 mm) diameter
Net Weight	9.2 oz (260 grams) without batteries
Accessories Included	AT8456a Quiet-Flex™ stand clamp
RF Power Output	10 mW
Battery Life	8 hours (alkaline); Depending on battery type and use pattern
Battery Type	Two 1.5V AA not included
Dimensions	2.76" (70.2 mm) W x 4.08" (103.7 mm) H x 0.98" (24.9 mm) D
Input Connections	Four-pin Locking Connector; Pin 1: GND; Pin 2: INST INPUT; Pin 3: MIC INPUT; Pin 4: DC BIAS +9V
Net Weight	2.8 oz (80.0 grams) without batteries
Spurious Emissions	Following federal and national regulations
Receiving System	Non-diversity, single-channel, dual antenna system
Image Rejection	50 dB minimum
RF Sensitivity	20 dBuV at 60 dB S/N ratio (50 ohms termination)
Power Supply	100-240V AC (50/60 Hz) to 12V DC .5A (center positive) switched mode external power supply
Operating Temperature Range	40° F (4° C) to 110° F (43° C)
Dimensions	7.48" (190.0 mm) W x 1.82" (46.2 mm) H x 5.06" (128.5 mm) D
Weight	12.0 oz (337 grams)
Accessories Included	Power supply
Audio Output	Nominal Output Level XLR, balanced: 350 mV (1 kHz modulation, 10 kHz deviation, 100k ohm load); 1/4" (6.3 mm), unbalanced: 700 mV (1 kHz modulation, 10 kHz deviation, 100k ohm load)
