Manufacturer Name
MPN
ATW-3212NC510DE2
SKU
TMU-ATW-3212NC510DE2
UPC
042005206568
Product Condition
NEW
The Audio-Technica ATW-3212NC510 3000 Series Wireless Handheld Microphone System is a network-enabled audio solution designed for professional wireless performance. This system provides the necessary hardware for high-quality vocal capture and reliable signal transmission.
The ATW-3212NC510 includes the ATW-R3210N network-enabled receiver and the ATW-T3202 handheld transmitter. These components facilitate a robust wireless connection, with the receiver offering specific features for network integration and system management.
The system features the ATW-C510 cardioid dynamic microphone capsule mounted on the handheld transmitter. This capsule utilizes a cardioid pickup pattern and dynamic element to capture audio effectively in handheld applications.
The ATW-R3210N receiver provides network-enabled functionality, allowing users to integrate the microphone system into a broader network infrastructure. This capability supports the monitoring and coordination of the 3000 Series wireless system components within a professional audio environment.
| Operating Frequencies | Band DE2: 470.125 to 529.975 MHz (2395 frequencies); Band EE1: 530.000 to 589.975 MHz (2400 frequencies); Band EF1: 590.000 to 649.975 MHz (2400 frequencies); Band FG1: 650.000 to 699.875 MHz (1996 frequencies). Please note that some frequency bands might not be available in your territory or could come with a limited tuning bandwidth / transmitting power due to local regulations. |
| Minimum Frequency Step | 25 kHz |
| Modulation Mode | FM |
| Maximum Deviation | ATW-T3201: ±38 kHz (THD:10%); ATW-T3202: ±36 kHz (THD:10%) |
| Frequency Response | ATW-T3201: 31 Hz to 15,500 Hz; ATW-T3202: 25 Hz to 16,700 Hz. Frequency response depends on attached microphone element. |
| Operating Range | 100 m (328'); Open range environment with no interfering signals. |
| Total Harmonic Distortion | <1.0% (at 1 kHz, ±17.5 kHz deviation) |
| Operating Temperature Range | -5° C to +45° C (23° F to 113° F) |
| Simultaneous Use | 40 Channels per band* (Region and band dependent). For assistance with multi-band operation or other frequency coordination issues, please contact your regional Audio-Technica customer service representative. |
| Handheld Transmitter | |
| RF Power Output | High: 30 mW, Low: 10 mW (switchable), at 50 ohms |
| Spurious Emissions | Following Federal and National Regulations |
| Microphone Capsule | Interchangeable industry standard thread |
| Battery Type | Two 1.5V AA, not included |
| Battery Life | High: 8.0 hours (alkaline), Low: 9.0 hours (alkaline); High: 9.0 hours (Ni-MH 1900mAh), Low: 9.5 hours (Ni-MH 1900mAh). Depending on battery type, usage, and environmental conditions. |
| Dimensions | ATW-T3202 (without capsule): 193 mm (7.60") long, 37 mm (1.46") maximum diameter; ATW-T3202/C510: 265 mm (10.43") long, 54 mm (2.13") maximum diameter; ATW-T3202/C710: 271 mm (10.67") long, 50 mm (1.97") maximum diameter |
| Net Weight | ATW-T3202 (without capsule): 200 g (7.1 oz), without batteries; ATW-T3202/C510: 330 g (11.6 oz), without batteries; ATW-T3202/C710: 314 g (11.1 oz), without batteries |
| Body Pack | |
| RF Power Output | High: 30 mW, Low: 10 mW (switchable), at 50 ohms |
| Battery Life | High: 8.0 hours (alkaline), Low: 9.0 hours (alkaline); High: 9.0 hours (Ni-MH 1900mAh), Low: 9.5 hours (Ni-MH 1900mAh). Depending on battery type, usage, and environmental conditions. |
| Battery Type | Two 1.5V AA, not included |
| Dimensions | 64 mm x 82 mm x 23 mm (W x D x H); 2.52" x 3.22" x 0.91" (W x D x H) |
| Input Connections | cH-style screw-down 4-pin connector; Pin 1: GND; Pin 2: INST INPUT; Pin 3: MIC INPUT; Pin 4: DC BIAS +5V |
| Net Weight | 102 g (3.6 oz), without batteries |
| Spurious Emissions | Following Federal and National Regulations |
| High-pass (low-freq. roll-off) | 125 Hz, 12 dB/octave |
| Receiver | |
| Receiving System | True Diversity |
| Image Rejection | 60 dB nominal |
| RF Sensitivity | 20 dBuV at 60 dBA S/N ratio (50 ohms termination) |
| Maximum Output Level | XLR, balanced: +14 dBV; 6.3 mm (1/4"), unbalanced: +8 dBV |
| Antenna Input | BNC-type, 50 ohms |
| Antenna Power | 12 V DC, 160 mA (combined) |
| Power Supply | 100-240V AC (50/60 Hz) to 12V DC 1A (center positive) switched mode external power supply |
| Dimensions | 210.0 mm x 191.0 mm x 43.4 mm (W x D x H); 8.27" x 7.52" x 1.71" (W x D x H) |
| Weight | 1100 g (38.8 oz), without accessories |
| Accessories Included | Two flexible UHF antennas; AC adapter (country dependent); rack-mount adapters |
| Length | 14.96 In. |
|---|---|
| Width | 13.39 In. |
| Height | 2.95 In. |
| Weight | 6.08 lbs |
