Audio-Technica ATW-3212N 3000 Series Wireless Handheld Microphone System (Network-Enabled)

System Components

The ATW-3212N system is comprised of two core hardware units that work together to ensure stable wireless performance.

ATW-R3210 Receiver

The ATW-R3210 receiver serves as the primary interface for the wireless system. This unit is network-enabled, allowing users to monitor and control system parameters over a network connection for improved operational efficiency.

ATW-T3202 Handheld Transmitter

The ATW-T3202 handheld transmitter acts as the mobile component of the system. This unit is provided as a transmitter handle, offering a durable foundation for the microphone assembly.

Configuration and Requirements

This system is designed with a modular approach to accommodate different audio needs.

Transmitter Handle: The included ATW-T3202 is the transmitter handle only.

Capsule Requirement: A microphone capsule is required to operate the transmitter.

Sold Separately: The microphone capsule must be purchased separately and is not included in the standard ATW-3212N package.

Network Connectivity: The network-enabled design facilitates integration into existing network infrastructures for remote system management.

Operating Frequencies	Band DE2: 470.125 to 529.975 MHz (2395 frequencies); Band EE1: 530.000 to 589.975 MHz (2400 frequencies); Band EF1: 590.000 to 649.975 MHz (2400 frequencies); Band FG1: 650.000 to 699.875 MHz (1996 frequencies). Please note that some frequency bands might not be available in your territory or could come with a limited tuning bandwidth / transmitting power due to local regulations.
Minimum Frequency Step	25 kHz
Modulation Mode	FM
Maximum Deviation	ATW-T3201: ±38 kHz (THD:10%); ATW-T3202: ±36 kHz (THD:10%)
Frequency Response	ATW-T3201: 31 Hz to 15,500 Hz; ATW-T3202: 25 Hz to 16,700 Hz. Frequency response depends on attached microphone element.
Operating Range	100 m (328'); Open range environment with no interfering signals.
Total Harmonic Distortion	<1.0% (at 1 kHz, ±17.5 kHz deviation)
Operating Temperature Range	-5° C to +45° C (23° F to 113° F)
Simultaneous Use	40 Channels per band* (Region and band dependent). For assistance with multi-band operation or other frequency coordination issues, please contact your regional Audio-Technica customer service representative.
Handheld Transmitter
RF Power Output	High: 30 mW, Low: 10 mW (switchable), at 50 ohms
Spurious Emissions	Following Federal and National Regulations
Microphone Capsule	Interchangeable industry standard thread
Battery Type	Two 1.5V AA, not included
Battery Life	High: 8.0 hours (alkaline), Low: 9.0 hours (alkaline); High: 9.0 hours (Ni-MH 1900mAh), Low: 9.5 hours (Ni-MH 1900mAh). Depending on battery type, usage, and environmental conditions.
Dimensions	ATW-T3202 (without capsule): 193 mm (7.60") long, 37 mm (1.46") maximum diameter; ATW-T3202/C510: 265 mm (10.43") long, 54 mm (2.13") maximum diameter; ATW-T3202/C710: 271 mm (10.67") long, 50 mm (1.97") maximum diameter
Net Weight	ATW-T3202 (without capsule): 200 g (7.1 oz), without batteries; ATW-T3202/C510: 330 g (11.6 oz), without batteries; ATW-T3202/C710: 314 g (11.1 oz), without batteries
Body Pack
RF Power Output	High: 30 mW, Low: 10 mW (switchable), at 50 ohms
Battery Life	High: 8.0 hours (alkaline), Low: 9.0 hours (alkaline); High: 9.0 hours (Ni-MH 1900mAh), Low: 9.5 hours (Ni-MH 1900mAh). Depending on battery type, usage, and environmental conditions.
Battery Type	Two 1.5V AA, not included
Dimensions	64 mm x 82 mm x 23 mm (W x D x H); 2.52" x 3.22" x 0.91" (W x D x H)
Input Connections	cH-style screw-down 4-pin connector; Pin 1: GND; Pin 2: INST INPUT; Pin 3: MIC INPUT; Pin 4: DC BIAS +5V
Net Weight	102 g (3.6 oz), without batteries
Spurious Emissions	Following Federal and National Regulations
High-pass (low-freq. roll-off)	125 Hz, 12 dB/octave
Receiver
Receiving System	True Diversity
Image Rejection	60 dB nominal
RF Sensitivity	20 dBuV at 60 dBA S/N ratio (50 ohms termination)
Maximum Output Level	XLR, balanced: +14 dBV; 6.3 mm (1/4"), unbalanced: +8 dBV
Antenna Input	BNC-type, 50 ohms
Antenna Power	12 V DC, 160 mA (combined)
Power Supply	100-240V AC (50/60 Hz) to 12V DC 1A (center positive) switched mode external power supply
Dimensions	210.0 mm x 191.0 mm x 43.4 mm (W x D x H); 8.27" x 7.52" x 1.71" (W x D x H)
Weight	1100 g (38.8 oz), without accessories
Accessories Included	Two flexible UHF antennas; AC adapter (country dependent); rack-mount adapters
