The Audio-Technica ATW-3212 3000 Series Wireless Handheld Microphone System provides a professional wireless solution for high-quality audio transmission.
The Audio-Technica ATW-3212 3000 Series Wireless Handheld Microphone System delivers reliable wireless audio transmission for professional environments. This system provides clear signal reproduction and stable connectivity for live vocal applications, presentations, and broadcasting.
The ATW-3212 configuration includes two primary hardware units designed to work in tandem for seamless audio capture:
The ATW-T3202 handheld transmitter is provided as a handle only. This design allows for flexible configuration, as the compatible microphone capsule is sold separately. Users can choose the specific capsule that meets their performance requirements to complete the handheld assembly.
| Operating Frequencies | Band DE2: 470.125 to 529.975 MHz (2395 frequencies); Band EE1: 530.000 to 589.975 MHz (2400 frequencies); Band EF1: 590.000 to 649.975 MHz (2400 frequencies); Band FG1: 650.000 to 699.875 MHz (1996 frequencies). Please note that some frequency bands might not be available in your territory or could come with a limited tuning bandwidth / transmitting power due to local regulations. |
| Minimum Frequency Step | 25 kHz |
| Modulation Mode | FM |
| Maximum Deviation | ATW-T3201: ±38 kHz (THD:10%); ATW-T3202: ±36 kHz (THD:10%) |
| Frequency Response | ATW-T3201: 31 Hz to 15,500 Hz; ATW-T3202: 25 Hz to 16,700 Hz. Frequency response depends on attached microphone element. |
| Operating Range | 100 m (328'); Open range environment with no interfering signals. |
| Total Harmonic Distortion | <1.0% (at 1 kHz, ±17.5 kHz deviation) |
| Operating Temperature Range | -5° C to +45° C (23° F to 113° F) |
| Simultaneous Use | 40 Channels per band* (Region and band dependent). For assistance with multi-band operation or other frequency coordination issues, please contact your regional Audio-Technica customer service representative. |
| Handheld Transmitter | |
| RF Power Output | High: 30 mW, Low: 10 mW (switchable), at 50 ohms |
| Spurious Emissions | Following Federal and National Regulations |
| Microphone Capsule | Interchangeable industry standard thread |
| Battery Type | Two 1.5V AA, not included |
| Battery Life | High: 8.0 hours (alkaline), Low: 9.0 hours (alkaline); High: 9.0 hours (Ni-MH 1900mAh), Low: 9.5 hours (Ni-MH 1900mAh). Depending on battery type, usage, and environmental conditions. |
| Dimensions | ATW-T3202 (without capsule): 193 mm (7.60") long, 37 mm (1.46") maximum diameter; ATW-T3202/C510: 265 mm (10.43") long, 54 mm (2.13") maximum diameter; ATW-T3202/C710: 271 mm (10.67") long, 50 mm (1.97") maximum diameter |
| Net Weight | ATW-T3202 (without capsule): 200 g (7.1 oz), without batteries; ATW-T3202/C510: 330 g (11.6 oz), without batteries; ATW-T3202/C710: 314 g (11.1 oz), without batteries |
| Body Pack | |
| RF Power Output | High: 30 mW, Low: 10 mW (switchable), at 50 ohms |
| Battery Life | High: 8.0 hours (alkaline), Low: 9.0 hours (alkaline); High: 9.0 hours (Ni-MH 1900mAh), Low: 9.5 hours (Ni-MH 1900mAh). Depending on battery type, usage, and environmental conditions. |
| Battery Type | Two 1.5V AA, not included |
| Dimensions | 64 mm x 82 mm x 23 mm (W x D x H); 2.52" x 3.22" x 0.91" (W x D x H) |
| Input Connections | cH-style screw-down 4-pin connector; Pin 1: GND; Pin 2: INST INPUT; Pin 3: MIC INPUT; Pin 4: DC BIAS +5V |
| Net Weight | 102 g (3.6 oz), without batteries |
| Spurious Emissions | Following Federal and National Regulations |
| High-pass (low-freq. roll-off) | 125 Hz, 12 dB/octave |
| Receiver | |
| Receiving System | True Diversity |
| Image Rejection | 60 dB nominal |
| RF Sensitivity | 20 dBuV at 60 dBA S/N ratio (50 ohms termination) |
| Maximum Output Level | XLR, balanced: +14 dBV; 6.3 mm (1/4"), unbalanced: +8 dBV |
| Antenna Input | BNC-type, 50 ohms |
| Antenna Power | 12 V DC, 160 mA (combined) |
| Power Supply | 100-240V AC (50/60 Hz) to 12V DC 1A (center positive) switched mode external power supply |
| Dimensions | 210.0 mm x 191.0 mm x 43.4 mm (W x D x H); 8.27" x 7.52" x 1.71" (W x D x H) |
| Weight | 1100 g (38.8 oz), without accessories |
| Accessories Included | Two flexible UHF antennas; AC adapter (country dependent); rack-mount adapters |
| Length | 13.07 In. |
|---|---|
| Width | 15.04 In. |
| Height | 3.03 In. |
| Weight | 5.73 lbs |
