Manufacturer Name
MPN
ATW-3211/831DE2
SKU
TMU-ATW-3211/831DE2
UPC
042005196173
Product Condition
NEW
The Audio-Technica ATW-3211/831 3000 Series Wireless Lavalier Microphone System is a professional wireless audio solution designed for clear and reliable vocal capture. This system facilitates high-quality sound transmission for presenters and performers by integrating advanced wireless components with a high-performance microphone.
The ATW-3211/831 system includes three primary hardware elements that ensure seamless audio operation:
The AT831cH microphone utilizes a cardioid polar pattern to focus on the primary sound source. This directional pickup pattern reduces the capture of unwanted ambient noise from the sides and rear, improving overall sound isolation. As a condenser microphone, it provides the sensitivity required for accurate vocal reproduction in various professional settings.
As part of the 3000 Series, the Audio-Technica ATW-3211/831 ensures consistent signal integrity. The combination of the ATW-R3210 receiver and the ATW-T3201 body-pack transmitter provides users with the flexibility to move freely without sacrificing audio quality. This system supports professional applications where clear communication and hardware reliability are essential.
| Operating Frequencies | UHF Band D: 656.125 to 678.500 MHz, Band I: 487.125 to 506.500 MHz, Band S: 508.125 - 526.825 MHz |
| Modulation Mode | FM |
| Maximum Deviation | ±40 kHz |
| Frequency Response | 100 Hz to 15 kHz (+1 dB, -3 dB) |
| Operating Range | 100 m (300'), typical - Open range environment with no interfering signals. |
| Total Harmonic Distortion | < 1% (at 1 kHz, ±20 kHz deviation) |
| Operating Temperature Range | 5º C to 45º C, 41º F to 113º F, Battery and LCD performance may be reduced at very low temperatures. |
| Number Of Channels | 10 total |
| Handheld Transmitter | |
| RF Power Output | High: 30 mW; Low: 10 mW (switchable), at 50 ohms |
| Spurious Emissions | Following federal and national regulations |
| Microphone Element | Dynamic cardioid |
| Battery Type | Two 1.5V AA alkaline (not included) or two 1.2V AA NiMH (not included) |
| Recharging Power for NiMH Batteries (with ATW-CHG2) | U.S./Canada/Latin America: 3.2 V DC, 230 mA x2; Other world areas: 3.2 V DC, 320 mA x2 |
| Battery Life | High: 7 hours (alkaline); Low: 9 hours (alkaline). Depending on battery type and use pattern. |
| Dimensions | 232.0 mm (9.13") long, 48.0 mm (1.89") diameter |
| Net Weight | 252 g (8.9 oz), without batteries |
| Accessories Included | AT8456a Quiet-Flex™ stand clamp |
| Body Pack | |
| RF Power Output | High: 30 mW, Low: 10 mW (switchable), at 50 ohms |
| Battery Life | High: 7 hours (alkaline); Low: 9 hours (alkaline). Depending on battery type and use pattern. |
| Battery Type | Two 1.5V AA alkaline (not included) or two 1.2V AA NiMH (not included) |
| Recharging Power for NiMH Batteries (with ATW-CHG2) | U.S./Canada/Latin America: 3.2 V DC, 230 mA x2; Other world areas: 3.2 V DC, 320 mA x2 |
| Dimensions | 66.0 mm (2.60") W x 22.5 mm (0.89") D x 92.3 mm (3.63") H |
| Input Connections | Four-pin Locking Connector — Pin 1: GND, Pin 2: INST INPUT, Pin 3: MIC INPUT, Pin 4: DC BIAS +9V |
| Net Weight | 81 g (2.9 oz), without batteries |
| Spurious Emissions | Following federal and national regulations |
| Receiver | |
| Receiving System | True diversity |
| Image Rejection | 60 dB nominal, 55 dB minimum |
| RF Sensitivity | 20 dBuV at 60 dB S/N ratio (50 ohms termination) |
| Maximum Output Level | XLR, balanced: +9 dBV, ¼" (6.3 mm), unbalanced: +4 dBV |
| Antenna Input | BNC-type, 50 ohms, Bias voltage 12V DC, 60 mA, each |
| Power Requirements | 12-18V DC, 500 mA |
| Dimensions | 210.0 mm (8.27") W x 162.2 mm (6.39") D x 44.0 mm (1.73") H. Not including BNC connectors or feet. |
| Weight | 1.0 kg (35.3 oz), without accessories |
| Accessories Included | Two flexible UHF antennas; AC adapter (country dependent); rack-mount adapters |
| Audio Output Attenuator (ATTN) | Balanced Audio Output Attenuator: Two position switch: 0 / -12 dB |
| Length | 13.07 In. |
|---|---|
| Width | 15.04 In. |
| Height | 3.03 In. |
| Weight | 5.07 lbs |
