StarBoard TE-DS-215WAD-S - Intelligent Display Hand Sanitizer Station

The StarBoard TE-DS-215WAD-S serves as a sophisticated Intelligent Display Hand Sanitizer Station, merging high-definition digital signage with automated hygiene protocols. This dual-purpose unit provides a touchless solution for high-traffic areas, ensuring safety while delivering targeted visual messaging through a 21.5-inch TFT LCD display. Engineered for commercial and public spaces, the device facilitates both interactive engagement and essential health maintenance in a single, streamlined form factor.

High-Performance Interactive Digital Signage

The core of the StarBoard TE-DS-215WAD-S is a vibrant 21.5-inch TFT LCD screen featuring a native resolution of 1920x1080. The 16:9 aspect ratio and 4000:1 contrast ratio ensure sharp, high-contrast visuals even in brightly lit environments.

• Advanced Processing Power: An A133 Quad-core 1.6GHz 64-bit processor provides the necessary performance for smooth media playback and application response.
• Modern Operating System: Running on Android 10, the station supports a wide range of content management applications and interactive software.
• Memory and Storage: Equipped with 2GB DDR3 RAM and 16GB EMMC internal memory, the device handles complex media files and high-definition video streams without latency.
• Precise Touch Interaction: The optional PCAP (Projected Capacitive) touch screen offers a responsive user interface for interactive maps, information kiosks, or feedback forms.

Advanced Touchless Hygiene System

The integrated hygiene station prioritizes safety through automated, non-contact technology. The system accommodates various sanitizing agents and utilizes secondary sterilization to maintain a clean environment.

• Versatile Discharge Modes: The internal dispensing mechanism supports spray, foam, or dripping soap configurations, allowing facilities to choose their preferred sanitizing medium.
• High-Capacity Reservoir: A 1000-1200ml product capacity reduces the frequency of refills in busy locations like airports, schools, or retail centers.
• Ultraviolet Disinfection: An integrated UV light source provides additional disinfection, enhancing the overall sanitary performance of the dispensing area.
• Touchless Operation: Infrared sensors detect hand proximity to discharge sanitizer automatically, eliminating cross-contamination risks associated with manual pumps.

Connectivity and Media Integration

The TE-DS-215WAD-S is built for seamless network integration and versatile content delivery. It supports a broad array of media formats to ensure compatibility with existing digital signage assets.

• Network Flexibility: Standard RJ45 10/100M Ethernet and 2.4G WiFi connectivity provide reliable options for remote content updates and device management.
• Peripheral Expansion: Multiple interfaces including three USB 2.0 ports, one Type-C port, and a 3.5mm audio jack allow for the connection of external sensors, peripherals, or sound systems.
• Broad Format Support: The onboard decoder handles H.265, VP9, and H.264 video formats at resolutions up to 4K at 30fps, ensuring high-fidelity playback of marketing videos and informational content.
• Wireless Expansion: Built-in Bluetooth 4.2 supports wireless peripheral expansion for enhanced functionality.

Industrial Build and Installation Options

Designed for durability in public spaces, the StarBoard TE-DS-215WAD-S features a robust build and flexible mounting configurations. The unit adapts to diverse architectural requirements through its modular design.

• Deployment Options: The station is available in both wall-mount and floor-stand configurations to suit specific floor plans and traffic flows.
• Physical Specifications: The floor-standing model has a net weight of 34.5kg, providing stability in high-traffic zones. The slim panel design maintains a modern aesthetic without sacrificing structural integrity.
• Global Power Compatibility: The power supply supports AC100-240V at 50/60Hz, making it suitable for international deployment with a low power rating of 20W.

Primary Applications and Use Cases

The StarBoard TE-DS-215WAD-S is optimized for environments where communication and hygiene are simultaneous priorities. Ideal locations include healthcare facilities, corporate lobbies, educational institutions, transportation hubs, and retail environments. By combining essential health services with high-impact digital communication, the station increases user engagement and supports public safety initiatives.
