StarBoard Solution FX-79E2 Four-Point Touch Interactive Whiteboard (79")

The StarBoard Solution FX-79E2 (IWB79) is a professional-grade 79-inch interactive whiteboard designed to enhance collaborative environments in educational and corporate settings. Utilizing an advanced Infrared Ray Shading Detection System, this board provides a highly responsive, finger-driven interface that eliminates the need for specialized active pens. The 4:3 aspect ratio and large active surface area facilitate comfortable group work and dynamic presentations, allowing multiple participants to interact with digital content simultaneously.

Advanced Multi-Touch and Collaborative Technology

The StarBoard FX-79E2 incorporates high-performance multi-touch capabilities that support up to four simultaneous users. This "4-Touch" feature enables students or team members to write, draw, and manipulate objects across the entire board surface at the same time. The infrared tracking system delivers a coordinate resolution of approximately 500 lpi and a tracking speed of 66 points per second, ensuring precise input with an accuracy of ±2.0mm. Users can control the interface through natural gestures, such as using a finger to annotate, a fist to scroll, or two fingers to zoom and erase.

Precision Hardware and Durable Construction

Engineered for high-traffic environments, the FX-79E2 features a robust build consisting of a high-density polyester core and a durable steel surface. The steel exterior is magnet-compatible, allowing the board to function as a traditional magnetic bulletin board when not powered. The hardware includes 15 integrated function buttons—distributed with 13 quick-access tools—to streamline navigation and tool selection. The unit operates via USB Bus Power (5V 500mA), eliminating the need for external power adapters and simplifying the installation process.

Versatile Software and System Integration

The included StarBoard Software provides a comprehensive suite of digital tools for content creation and delivery. It features multi-platform support for both Windows and Mac OS, offering a customizable floating toolbar to match individual workflows. Key software capabilities include:

• Handwriting Recognition: Converts manual notations into digital text (Windows only).
• Office Integration: Direct importing and annotation of Microsoft Office files including Word, Excel, and PowerPoint.
• Digital Inks: A wide variety of ink types for highlighting and detailed technical annotations.
• Remote Collaboration: Integrated conferencing features support remote participation and content sharing.
• Search Functionality: Direct access to Google Image search and the internet for real-time resource retrieval.

Technical Specifications and Requirements

The FX-79E2 maintains a slim profile with dimensions of 72.9"(W) x 50.5"(H) x 1.4"(D) and a weight of approximately 48.5 lbs. It connects to host computers via USB 1.1 or 2.0 interfaces. For optimal performance, Windows systems require an Intel Pentium 4 1.8GHz or higher, while Mac systems require an Intel-based processor. Remote conferencing features demand at least an Intel Core 2 Duo processor and 2GB of RAM. The device is certified with FCC Class B, CE, and VCCI Class A standards, ensuring compliance with international electromagnetic interference regulations.

Package Contents and Warranty

Each StarBoard FX-79E2 unit ships with the necessary components for immediate deployment. The package includes:

• 1 StarBoard FX-79E2 Interactive Whiteboard
• 1 Stylus Pen for precision input
• Wall mount bracket and USB cable
• StarBoard Software and Start-up Guide

The product is backed by a 2-year limited warranty, providing long-term reliability for institutional and commercial users.
