IOGEAR 4-Port Dual View DisplayPort Secure KVM Switch w/Audio and CAC Support - 4 Computer(s) - 1 Local User(s) - 3840 x 2160 - 50 Hz, 60 Hz - 1 x Network (RJ-45) - 11 x USB - 10 x DisplayPort TAA Compliant
IOGEAR 4-Port Dual View DisplayPort Secure KVM Switch w/Audio and CAC Support - 4 Computer(s) - 1 Local User(s) - 3840 x 2160 - 50 Hz, 60 Hz - 1 x Network (RJ-45) - 11 x USB - 10 x DisplayPort TAA Compliant
| KVM Type | Secure KVM Switch |
| Number of Computers Supported | 4 |
| Number of Local Users | 1 |
| Video Interface (Computer) | DisplayPort 1.2 |
| Video Interface (Console) | DisplayPort 1.2 |
| Maximum Video Resolution | 3840 x 2160 (4K UHD) |
| Maximum Refresh Rate | 60 Hz (at 4K UHD) |
| Dual View Support | Yes |
| Audio Support | Yes (Stereo Speakers & Microphone) |
| Common Access Card (CAC) Support | Yes |
| TAA Compliant | Yes |
| NIAP Certification | PP 4.0 (Protection Profile for Peripheral Sharing Devices) |
| USB Console Ports | 2 x USB Type-A (Keyboard, Mouse) |
| USB CAC Port | 1 x USB Type-A |
| USB Peripheral Ports | 4 x USB 2.0 Type-A (Transparent Mode) |
| Computer USB Input Ports | 4 x USB Type-B |
| Computer DisplayPort Inputs | 8 (4 computers x 2 DisplayPort) |
| Console DisplayPort Outputs | 2 |
| Console Audio Output | 1 x 3.5mm Stereo Jack |
| Console Microphone Input | 1 x 3.5mm Stereo Jack |
| Computer Audio Input | 4 x 3.5mm Stereo Jack |
| Computer Microphone Input | 4 x 3.5mm Stereo Jack |
| Management Port | 1 x RJ-45 (Firmware Upgrade Only) |
| Switching Method | Front Panel Push Buttons, Hotkeys, OSD (On-Screen Display) |
| Keyboard/Mouse Emulation | Yes |
| Operating System Compatibility | Windows, macOS, Linux |
| Power Supply | External Power Adapter |
| Chassis Material | Metal |
| LED Indicators | Port Selection, Status |
| Operating Temperature | 32°F to 104°F (0°C to 40°C) |
| Storage Temperature | -4°F to 140°F (-20°C to 60°C) |
| Humidity Range | 0% to 80% RH, Non-Condensing |
| Length | 0.3 In. |
|---|---|
| Width | 0.7 In. |
| Height | 0.5 In. |
| Weight | 0.9 lbs |
